HDS5D18-220NTR

$0.18

Description：IND 22UH 0.8A 0.29OHM 30% SMD
Series：-
Mfr：HALO Electronics, Inc.
Package：Tape & Reel (TR)

SKU:22efeb564df5 Category: Fixed Inductors Brand: HALO Electronics, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HDS5D18-220NTR is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists HALO Electronics, Inc.. Its product description is IND 22UH 0.8A 0.29OHM 30% SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for HDS5D18-220NTR

Description：IND 22UH 0.8A 0.29OHM 30% SMD
Series：-
Mfr：HALO Electronics, Inc.
Package：Tape & Reel (TR)
Type：Drum Core, Wirewound
Material - Core：-
Inductance：22 µH
Tolerance：±30%
Current Rating (Amps)：800 mA
Current - Saturation (Isat)：-
Shielding：Shielded
DC Resistance (DCR)：290mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.126" L x 0.126" W (3.20mm x 3.20mm)
Height - Seated (Max)：0.079" (2.00mm)
Features：-

Fixed Inductors datasheet and documents for HDS5D18-220NTR

HDS5D18-220NTR

Fixed Inductors Overview

The HDS5D18-220NTR is a shielded surface-mount power inductor from HALO Electronics, utilizing a DrumCore wirewound design. It features an inductance of 22 µH with a tolerance of 30%. The component has a maximum DC resistance of 290 mOhms and supports a maximum DC current of 800 mA. Measuring 6.2 mm x 6.2 mm x 2 mm, it operates within a temperature range of -40°C to +85°C. Testing is conducted at 100 kHz.

Fixed Inductors Feature Summary

Shielded DrumCore construction for reduced electromagnetic interference
Surface-mount package optimized for PCB integration
Wirewound core technology ensuring stable performance

Fixed Inductors Applications

Power supply circuits
DC-DC converter modules
General power electronics filtering

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official HALO Electronics documentation to confirm electrical parameters and physical dimensions. Ensure compatibility with automated pick-and-place equipment due to the surface-mount form factor. Check for any recent product change notifications regarding lead times or material composition updates before finalizing procurement plans.

Fixed Inductors Selection Notes

Select this component when a 22 µH inductance value is required with a compact 6.2 mm footprint. Consider the 800 mA current rating and 290 mOhm resistance for thermal management in space-constrained designs. Verify that the operating temperature range meets the environmental requirements of the target application.

Fixed Inductors Part Context

This component belongs to the HDS series of shielded drum core power inductors manufactured by HALO Electronics. The series offers various inductance values within a consistent physical envelope, facilitating standardized board layouts across different power stages. The HDS5D18-220NTR specifically provides higher inductance compared to lower-value variants in the same package size.
