Product Detailed Parameters
- Description：RF FILTER HI PASS 1.3GHZ 16ULGA
- Series：HF
- Mfr：KYOCERA AVX
- Package：Bulk
- Frequency：1.3GHz
- Bandwidth：-
- Filter Type：High Pass
- Ripple：-
- Insertion Loss：1.2dB
- Mounting Type：Surface Mount
- Package / Case：16-ULGA
- Size / Dimension：0.259" L x 0.156" W (6.58mm x 3.98mm)
- Height (Max)：0.022" (0.56mm)
Download product information
Overview
The HF0AA1300A700 is a high-pass filter from the KYOCERA AVX HF series, designed for signal conditioning applications. It operates at a cutoff frequency of 1.3 GHz with a bandwidth of 5.7 GHz. The component features a 50 Ohm impedance and utilizes SMD/SMT termination types. It is housed in a compact 2616 (6640 metric) package, suitable for board mount installation. The device supports an operating temperature range from -55 C to +85 C.
Feature Summary
- Provides high-pass filtering for RF signal conditioning
- Supports multiple wireless standards across various frequency bands
- Features a low-profile design with thickness less than 1.0mm
Applications
- Wireless communication systems requiring specific band filtering
- RF front-end modules in mobile devices
- Signal conditioning circuits in telecommunications equipment
Procurement Notes
Verify the exact datasheet specifications against the manufacturer's official documentation before integration. Confirm that the 2616 package dimensions and thermal characteristics align with your PCB layout constraints. Ensure the operating temperature range meets your environmental requirements. Cross-reference the part number with authorized distributors to avoid counterfeit components.
Selection Notes
Select this component when a high-pass filter with a 1.3 GHz cutoff is required in a small form factor. The 50 Ohm impedance matches standard RF transmission lines. Consider the 2616 package size for space-constrained designs. Verify compatibility with surface mount assembly processes. Evaluate the bandwidth requirements to ensure it suits the target application spectrum.
Part Context
This part belongs to the KYOCERA AVX HF series of MLO filters. These components are engineered for high-frequency applications where size and performance are critical. The series offers various cutoff frequencies to support different wireless standards. They are widely used in modern electronic devices requiring efficient signal management.
FAQ
What is the physical package size of the HF0AA1300A700?
The component is available in a 2616 (6640 metric) package.
Does the HF0AA1300A700 have a low profile?
Yes, MLO filters in this series typically have a thickness of less than 1.0mm.
