HF0AA1800A700

Overview

The HF0AA1800A700 is a high-pass filter from the KYOCERA AVX HF series, designed for signal conditioning applications. It operates at a center frequency of 1.8 GHz with a bandwidth of 1.14 GHz. The component features a 50 Ohm impedance and utilizes SMD/SMT mounting in a 1608 metric package. Key electrical specifications include an insertion loss of 1.2 dB. It functions within a temperature range of -55°C to +85°C.

Feature Summary

• Utilizes thin-film multilayer technology for stable high-frequency performance
• Designed for surface-mount board integration
• Provides high-pass filtering characteristics for signal conditioning

Applications

• RF signal conditioning circuits
• Wireless communication systems
• High-frequency electronic equipment

Procurement Notes

Verify current availability and lead times directly with authorized distributors or the manufacturer, as production cycles may vary. Confirm RoHS compliance status and specific ordering suffixes against official datasheets before procurement. Ensure compatibility with existing supply chain requirements and minimum order quantities.

Selection Notes

Select this component for applications requiring a 1.8 GHz high-pass filter with low insertion loss. Consider the 1608 package size for space-constrained designs. Verify that the 50 Ohm impedance matches system requirements. Check thermal ratings against operational environments.

Part Context

This part belongs to the KYOCERA AVX HF series of RF filters. These components are engineered using thin-film technology to offer reliable performance across a wide frequency range. The series supports various signal conditioning needs in modern electronic devices.
