HF0AA3280A700

$17.73

Description：RF FILT HIGH PASS 3.28GHZ 16ULGA
Series：HF
Mfr：KYOCERA AVX
Package：Bulk

SKU:3062e6f7b4d9 Category: RF Filters Brand: KYOCERA AVX

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILT HIGH PASS 3.28GHZ 16ULGA
Series：HF
Mfr：KYOCERA AVX
Package：Bulk
Frequency：3.28GHz
Bandwidth：-
Filter Type：High Pass
Ripple：-
Insertion Loss：1.2dB
Mounting Type：Surface Mount
Package / Case：16-ULGA
Size / Dimension：0.259" L x 0.156" W (6.58mm x 3.98mm)
Height (Max)：0.022" (0.56mm)

Download product information

HF0AA3280A700

Overview

The KYOCERA AVX HF0AA3280A700 is a surface-mount high-pass filter operating at a center frequency of 3.28 GHz with a bandwidth of 5.22 GHz. It features a 50 Ohm impedance and utilizes MLO® multilayer organic technology within a 2616 (16-ULGA) package. The component exhibits an insertion loss of 1.2 dB and supports board mounting in temperatures ranging from -55°C to +85°C.
