HF0AA6240A700

Overview

The KYOCERA AVX HF0AA6240A700 is a high-pass filter designed for signal conditioning applications. It operates within a frequency range of 6.24 GHz to 8 GHz with a 50 Ohms impedance. The component utilizes SMD/SMT termination and is housed in a 2616 (6640 metric) package. It features an insertion loss of 0.8 dB and functions reliably between -55 C and +85 C. This device belongs to the HF series and employs Multilayer Organic technology.

Feature Summary

• Built on patented Multilayer Organic high density interconnect technology
• Provides high-frequency performance suitable for RF signal conditioning
• Designed for board mount installation via surface mount terminals

Applications

• RF signal filtering in communication systems
• High-frequency circuit protection
• Signal conditioning modules

Procurement Notes

Verify current availability status directly with authorized distributors or the manufacturer, as supply levels may vary. Confirm RoHS compliance details and specific ordering suffixes required for your production needs. Ensure compatibility with your PCB layout specifications regarding the 2616 package dimensions before finalizing procurement orders.

Selection Notes

Select this component when a high-pass filter is required for frequencies starting at 6.24 GHz up to 8 GHz. The 50 Ohms impedance matches standard RF system requirements. Consider the 2616 package size for space-constrained designs requiring surface mount integration. Verify thermal operating limits against your environmental conditions.

Part Context

This part belongs to the KYOCERA AVX HF series of high-pass filters. These components utilize Multilayer Organic technology to deliver robust performance in demanding RF environments. The series offers various cutoff frequencies while maintaining consistent impedance and packaging standards for standardized design integration.

Replacement Considerations

Check datasheets for alternative models within the HF series that match the 6.24 GHz cutoff frequency and 2616 package footprint. Ensure any substitute maintains the 50 Ohms impedance and similar insertion loss characteristics to preserve circuit performance without redesign.
