HF0BA0930A700

Overview

The KYOCERA AVX HF0BA0930A700 is a surface-mount high-pass filter designed for signal conditioning applications. It operates at a cutoff frequency of 930 MHz with a bandwidth of 690 MHz. The component features a 50 Ohm impedance and utilizes SMD/SMT termination types. It is housed in a 3116 (7840 metric) package, suitable for board mount installation. The device functions within a temperature range of -55°C to +85°C and belongs to the HF series under the MLO trademark.

Feature Summary

• Provides high-pass filtering characteristics for RF signal conditioning
• Designed for surface-mount technology integration on printed circuit boards
• Operates with a standard 50 Ohm system impedance

Applications

• RF signal path filtering
• Microwave circuit design
• Wireless communication systems

Procurement Notes

Verify current availability status as lead times may vary significantly. Confirm specific ordering suffixes if tape-and-reel packaging is required instead of waffle pack. Ensure compatibility with existing PCB footprint dimensions for the 3116 case size before finalizing procurement plans.

Selection Notes

Select this component when a 930 MHz high-pass response is required in a compact 3116 package. Consider the 690 MHz bandwidth and 0.84 dB insertion loss specifications for signal integrity requirements. Verify that the operating temperature range meets the environmental conditions of the target application.

Part Context

This part belongs to the KYOCERA AVX HF series of passive filters. It is categorized under signal conditioning products, specifically high-pass filters. The manufacturer identifies it with the MLO trademark. It is distinct from other frequencies in the same series, such as the HF0DA0740A700 or HF0BA1540A700 models.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Engineers should verify pinout and electrical parameter compatibility if considering alternative manufacturers or different model numbers within the same series.
