HF0BA1500A700

Overview

The KYOCERA AVX HF0BA1500A700 is a high-pass RF filter designed for signal conditioning applications. It operates at a frequency of 1.5 GHz with a bandwidth of 1.33 GHz and features an impedance of 50 Ohms. The device utilizes SMD/SMT mounting in a 3116 (7840 metric) package. Key electrical specifications include an insertion loss of 0.75 dB. The component supports a minimum operating temperature of -55 C and a maximum operating temperature of +85 C.

Feature Summary

• High-pass filtering capability for precise signal conditioning
• Surface-mount construction for automated board assembly
• Optimized for high-frequency RF performance

Applications

• RF signal conditioning circuits
• High-frequency communication systems
• Broadband wireless infrastructure

Procurement Notes

Verify the specific datasheet version to confirm current RoHS compliance status and detailed electrical tolerances before integration. Ensure that the 3116 package dimensions align with the target PCB footprint. Confirm that the operating temperature range meets the environmental requirements of the final application. Cross-reference the manufacturer part number with authorized distributors to ensure authenticity and traceability.

Selection Notes

Select this component when a high-pass filter is required at 1.5 GHz with low insertion loss. The 50 Ohm impedance matches standard RF transmission lines. The surface-mount package facilitates compact design. Consider thermal limits if the environment exceeds 85 C. Verify bandwidth requirements against the 1.33 GHz specification to ensure adequate signal rejection below the cutoff frequency.

Part Context

This component belongs to the HF series of high-pass filters from KYOCERA AVX. These devices are engineered for precision RF applications requiring stable performance. The MLO trademark indicates specific manufacturing technology used for these filters. The series provides solutions for modern communication systems demanding miniaturization and reliability.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official manufacturer channels for potential alternatives or updated product line information.

FAQ

What is the package type for this filter?

The device uses a 3116 (7840 metric) surface-mount package.

Does this component support surface mount technology?

Yes, the end type is specified as SMD/SMT for board mounting.
