FFC, FPC (Flat Flexible) Connector Assemblies HFW25S-4STZE1HLF product image

HFW25S-4STZE1HLF

$0.23

Description：CONN FFC FPC VERT 25POS 1MM SMD
Series：HFW-S
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)

SKU:884f1d345bef Category: FFC, FPC (Flat Flexible) Connector Assemblies Brand: Amphenol ICC (FCI)

ChipApex WhatsApp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HFW25S-4STZE1HLF is listed in the FFC, FPC (Flat Flexible) Connector Assemblies range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN FFC FPC VERT 25POS 1MM SMD. Review the specifications below when checking this part for your BOM.

FFC, FPC (Flat Flexible) Connector Assemblies specifications for HFW25S-4STZE1HLF

Description：CONN FFC FPC VERT 25POS 1MM SMD
Series：HFW-S
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)
Flat Flex Type：FFC, FPC
Mounting Type：Surface Mount
Connector/Contact Type：Contacts, Vertical - 1 Sided
Number of Positions：25
Pitch：0.039" (1.00mm)
Termination：Solder
FFC, FCB Thickness：0.30mm, 0.33mm
Height Above Board：0.209" (5.30mm)
Locking Feature：-
Cable End Type：Straight, Tapered
Contact Material：Phosphor Bronze
Contact Finish：Tin
Housing Material：Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free
Actuator Material：-
Features：-
Voltage Rating：100V
Operating Temperature：-
Material Flammability Rating：UL94 V-0

FFC, FPC (Flat Flexible) Connector Assemblies datasheet and documents for HFW25S-4STZE1HLF

HFW25S-4STZE1HLF
