HG2403U-NMO

Antennas RF Overview

The HG2403U-NMO is a dual-band omnidirectional mobile-mount antenna manufactured by L-com. It operates in the 900 MHz and 2.4 GHz frequency bands, providing broad coverage for wireless systems. The antenna features an NMO connector type and utilizes a magnetic mounting method for vehicle installation. It offers a gain of 3 dBi and supports a maximum power input of 100 W. The unit has a maximum height of 8.0 inches (203.20 mm) and complies with RoHS3 standards.

Antennas RF Feature Summary

• Dual-band operation supporting both 900 MHz and 2.4 GHz frequencies
• Omnidirectional radiation pattern for broad signal coverage
• Magnetic base mount designed for mobile vehicle applications
• NMO connector interface for standard mobile radio integration

Antennas RF Applications

• Mobile two-way radio communications
• Wireless LAN (WLAN) connectivity
• Bluetooth device connections
• RFID system installations
• GSM network equipment

Antennas RF Procurement Notes

Verify that the specific order matches the HG2403U-NMO model number to ensure correct dual-band functionality. Confirm the presence of the NMO connector on the receiving equipment before purchase. Check for RoHS3 compliance requirements if environmental regulations apply to the deployment site. Ensure the mounting surface is suitable for magnetic attachment to maintain signal integrity during movement.

Antennas RF Selection Notes

Select this component when dual-band support for both sub-GHz and 2.4 GHz ISM bands is required in a single compact unit. The NMO mount makes it suitable for vehicles where drilling is prohibited. Consider the 3 dBi gain level for general mobile coverage needs rather than long-range directional links. Verify that the 100 W power rating aligns with the transmitter output specifications of the connected radio equipment.

Antennas RF Part Context

This antenna belongs to the HyperLink series from L-com, which focuses on wireless connectivity solutions. The HG2403U-NMO is part of a family of mobile antennas designed for rugged environments. It serves as a versatile solution for integrating multiple wireless protocols into mobile platforms without requiring separate antennas for different frequency bands.

Antennas RF Replacement Considerations

The HG2405U-NMO is a related single-band variant operating at 2.4 GHz with higher gain. Substitution requires verifying if the 900 MHz band is necessary, as the replacement lacks this capability. Connector compatibility and mounting style remain consistent between these models.
