HG2404U

Antennas RF Overview

The L-com HG2404U is a 2.4 to 2.5 GHz omnidirectional RF antenna designed for WiFi, WLAN, Bluetooth, and ISM applications. It features a 4 dBi gain rating and a 50-ohm impedance. The unit utilizes an N-type male connector and includes a magnetic base with a straight whip design. This HGV-Series component supports 802.11b/g/n protocols and is engineered for all-weather outdoor operation.

Antennas RF Feature Summary

• Omnidirectional radiation pattern for consistent signal coverage
• Integrated magnetic mounting base for flexible installation
• Compact lightweight construction suitable for pole or surface mounting

Antennas RF Applications

• WiFi and WLAN network infrastructure
• Bluetooth and BLE connectivity systems
• ISM band industrial communication devices

Antennas RF Procurement Notes

Verify the specific connector gender and frequency range against project requirements. Confirm that the N-type male interface matches existing cabling. Ensure the magnetic base provides sufficient holding force for the intended mounting location. Check environmental ratings if exposure to extreme weather conditions is expected.

Antennas RF Selection Notes

Select this model when a low-profile omnidirectional solution is required for 2.4 GHz bands. The 4 dBi gain offers a balance between range and size. Consider the magnetic base for temporary setups or locations where drilling is prohibited. Verify compatibility with standard N-type coaxial cables.

Antennas RF Part Context

This antenna belongs to the L-com HGV-Series, which focuses on lightweight and compact designs for reliable outdoor performance. The series typically includes pole mounting brackets for secure attachment. L-com specializes in industrial-grade wired and wireless interconnect solutions.

Antennas RF Replacement Considerations

No public substitute part numbers are confirmed in available documentation.
