HG2405P-135-RSP

Antennas RF Overview

The L-com HG2405P-135-RSP is a 2.4 GHz patch antenna with a 5 dBi gain rating, designed for wide-angle coverage in WLAN applications. It operates within the 802.11b/g/n frequency bands and features an RP-SMA plug connector attached to a 4-foot pigtail cable. The unit supports both horizontal and vertical polarization installation options.

Antennas RF Feature Summary

• Wide-angle radiation pattern optimized for broad coverage areas
• Dual spatial MIMO capability for enhanced signal reliability
• Flexible mounting configuration supporting horizontal or vertical polarization

Antennas RF Applications

• Indoor wireless LAN infrastructure deployment
• Enterprise Wi-Fi network expansion
• High-density client environment connectivity

Antennas RF Procurement Notes

Verify that the specific order matches the HG2405P-135-RSP designation, ensuring the inclusion of the 4-foot RP-SMA plug pigtail. Confirm compatibility with existing RP-SMA female ports on access points or routers. Request official datasheets to validate the 5 dBi gain specification and 2.4 GHz operational range prior to finalizing procurement.

Antennas RF Selection Notes

Select this model when wide-angle coverage is required for 2.4 GHz networks without the need for dual-band operation. The integrated 4-foot cable facilitates flexible placement away from mounting surfaces. Ensure the RP-SMA interface aligns with the target device's connector type to avoid additional adapters.

Antennas RF Part Context

This component belongs to the HyperLink Wireless flat panel antenna series, which includes dual-band variants like the HG2458-5P. The HG2405P-135-RSP specifically addresses single-band 2.4 GHz requirements, offering a cost-effective solution for standard 802.11b/g/n deployments compared to multi-band alternatives.

Antennas RF Replacement Considerations

The HG2405P-135-NF serves as a direct functional alternative if an N-Female connector is preferred over the RP-SMA plug. For dual-band 2.4/5.8 GHz requirements, the HG2458-5P-135-RSP provides equivalent form factor with extended frequency support.
