HG2405RD-1-NM

Antennas RF Overview

The HG2405RD-1-NM is a rubber duck antenna manufactured by L-com, designed for RF applications in the 2.4GHz to 2.5GHz frequency range. It features an RP-TNC male connector and provides a gain of 5dBi. The antenna supports standards including Bluetooth, Wi-Fi, WLAN, and ISM bands. It has a maximum height of 8.200 inches (208.28mm) and a VSWR of 2.

Antennas RF Feature Summary

• Flexible rubber duck design with tilting capability
• Omni-directional radiation pattern
• RP-TNC male connector interface

Antennas RF Applications

• Bluetooth devices
• Wi-Fi networks
• WLAN systems
• ISM band applications

Antennas RF Procurement Notes

Verify the specific connector gender and type against project requirements, as the model suffix indicates an RP-TNC male connector. Confirm that the operating frequency range of 2.4GHz to 2.5GHz aligns with the target wireless standard. Ensure the mounting method accommodates the connector installation type and physical dimensions.

Antennas RF Selection Notes

Select this component when a flexible, tilting antenna is required for 2.4GHz wireless protocols. The 5dBi gain offers a balance between size and performance for short-range communications. The RP-TNC connector is common in consumer electronics and industrial modules requiring non-standard mating interfaces.

Antennas RF Part Context

This part belongs to the HG series of HyperLink Wireless antennas from L-com. These are typically omni-directional rubber duck antennas optimized for 2.4GHz ISM band operations. The series includes variants with different connectors and gain specifications to suit diverse integration needs.

Antennas RF Replacement Considerations

Check for other HG series models with compatible connectors if the RP-TNC male variant is unavailable. Verify that any substitute maintains the 2.4GHz frequency range and similar gain characteristics.
