HG2409Y-NM

$87.56

Description：ANTYAGI 2.4GHZ 9DBI
Series：HG
Mfr：L-com
Package：Bag

SKU:a6a56dfe79c2 Category: RF Antennas Brand: L-com

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HG2409Y-NM is listed in the Antennas RF range at ChipApex. The manufacturer field lists L-com. Its product description is ANTYAGI 2.4GHZ 9DBI. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for HG2409Y-NM

Description：ANTYAGI 2.4GHZ 9DBI
Series：HG
Mfr：L-com
Package：Bag
RF Family/Standard：Bluetooth, General ISM, WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：Yagi
Number of Bands：1
VSWR：1.5
Return Loss：-
Gain：9dBi
Features：-
Termination：Screw-Mount
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Mast Mount
Height (Max)：6.000" (152.40mm)
Applications：802.11b/g, Bluetooth, ISM, Wi-Fi, WLAN
Power - Max：50 W

Antennas RF datasheet and documents for HG2409Y-NM

HG2409Y-NM

Antennas RF Overview

The L-Com HG2409Y-NM is a 2.4 GHz Yagi antenna with 9 dBi gain and a 60-degree beamwidth. It features a UV-stable, UL flame-rated radome enclosure and DC short lightning protection. The unit includes a 12-inch coaxial lead terminated with an N-Female connector.

Antennas RF Feature Summary

Radome enclosed design for environmental durability
High directional gain with narrow beamwidth
Integrated lightning protection via DC short circuit

Antennas RF Applications

Directional wireless LAN links
Point-to-point microwave communication
Outdoor RF signal transmission

Antennas RF Procurement Notes

Verify the specific connector gender matches system requirements. Confirm frequency range compatibility with operating equipment. Check radome material ratings for environmental exposure. Ensure mounting hardware supports structural load.

Antennas RF Selection Notes

Choose this model for applications requiring high directivity at 2.4 GHz. The radome design suits outdoor deployment. Verify cable length needs against the fixed 12-inch lead. Consider beamwidth constraints for coverage area.

Antennas RF Part Context

This component belongs to the HyperGain series of directional antennas. It utilizes Yagi-Uda array principles for focused radiation patterns. The product line targets industrial and commercial wireless infrastructure needs.

Antennas RF Replacement Considerations

HG2409Y-NF offers identical specifications with an N-Female connector variant. Cross-reference connector types carefully to ensure interface compatibility during substitution.
