HG2409Y-RSP

$91.59

Description：ANTYAGI 2.4GHZ 9DBI
Series：HG
Mfr：L-com
Package：Bag

SKU:d95bfa468e11 Category: RF Antennas Brand: L-com

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HG2409Y-RSP is listed in the Antennas RF range at ChipApex. The manufacturer field lists L-com. Its product description is ANTYAGI 2.4GHZ 9DBI. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for HG2409Y-RSP

Description：ANTYAGI 2.4GHZ 9DBI
Series：HG
Mfr：L-com
Package：Bag
RF Family/Standard：Bluetooth, General ISM, WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：Yagi
Number of Bands：1
VSWR：1.5
Return Loss：-
Gain：9dBi
Features：-
Termination：Screw-Mount
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Mast Mount
Height (Max)：6.000" (152.40mm)
Applications：802.11b/g, Bluetooth, ISM, Wi-Fi, WLAN
Power - Max：50 W

Antennas RF datasheet and documents for HG2409Y-RSP

HG2409Y-RSP

Antennas RF Overview

The L-com HG2409Y-RSP is a 2.4 GHz Yagi antenna with 9 dBi gain, designed for wireless LAN signal enhancement and directional transmission. It features an RP-SMA connector and includes a 12-inch (0.3 m) pigtail cable. The radome-enclosed design supports vertical or horizontal polarization installation.

Antennas RF Feature Summary

Directional Yagi design for focused signal transmission
Radome enclosure for environmental protection
Supports flexible vertical or horizontal polarization mounting

Antennas RF Applications

Wireless LAN signal extension
Point-to-point communication links
Outdoor WiFi network deployment

Antennas RF Procurement Notes

Verify the exact model suffix to confirm connector type and cable length specifications. Ensure compatibility with existing RP-SMA interfaces in the target system. Cross-reference official datasheets for precise mechanical dimensions and environmental ratings before finalizing procurement decisions.

Antennas RF Selection Notes

Select this model when directional gain is required over omnidirectional coverage. Consider the fixed 12-inch cable length for installation flexibility. Verify that the RP-SMA interface matches the connected radio equipment. Evaluate environmental exposure requirements against the radome protection capabilities.

Antennas RF Part Context

This component belongs to L-com's HG2409Y series of 2.4 GHz Yagi antennas. Variants within the series differ primarily by connector type and cable length, such as the N-type or TNC options. All models share the same 9 dBi gain and directional radiation pattern characteristics.
