HLMP-LM75-34QDD

LED Indication - Discrete Overview

The HLMP-LM75-34QDD is a through-hole light-emitting diode manufactured by Broadcom Limited. It features a blue lens and emits green light with a peak wavelength of 565 nm. The component utilizes a T-1 3/4 (5mm) package design with two pins for mounting. Typical forward voltage is specified at 2.2 V when tested at a current of 20 mA. The device provides a luminous intensity of 8 mcd and offers a viewing angle of 30 x 70 degrees. Its physical dimensions are approximately 5.4 mm in width and 8.7 mm in length, suitable for standard panel or board applications requiring visible indication.

LED Indication - Discrete Feature Summary

• Emits green light within the visible spectrum
• Utilizes a translucent blue lens housing
• Designed for through-hole PCB mounting

LED Indication - Discrete Applications

• Panel status indicators
• Equipment power state signaling
• General purpose visual alerts

LED Indication - Discrete Procurement Notes

Verify the specific suffix code against official Broadcom documentation to confirm optical characteristics and binning. Ensure compatibility with existing fixture designs for through-hole assembly processes. Confirm lead-free compliance requirements if applicable to your manufacturing standards. Cross-reference datasheet revisions to ensure parameter consistency.

LED Indication - Discrete Selection Notes

Select this component where green visibility is required alongside a blue aesthetic housing. Consider the 30 x 70 degree viewing angle for directional indication needs. Evaluate the 2.2 V forward voltage drop for circuit driver compatibility. Ensure mechanical fit within the 5.4 x 8.7 mm footprint constraints of the target enclosure.

LED Indication - Discrete Part Context

This part belongs to Broadcom's discrete LED portfolio, specifically the HLMP series designed for general indication purposes. These components are engineered for reliability in consumer electronics and industrial equipment. The T-1 3/4 form factor remains a standard choice for legacy and modern panel interfaces requiring robust visual feedback.

LED Indication - Discrete Replacement Considerations

Consult official substitution guides for equivalent green LEDs with matching pin configurations and luminous intensity ranges. Verify that alternative packages maintain the same mechanical dimensions and thermal characteristics.
