Product Detailed Parameters
- Description：FIXED IND 150NH 23.3A 2.5 MOHM
- Series：HM72B
- Mfr：TT Electronics/BI Magnetics
- Package：Cut Tape (CT)
- Type：Molded
- Material - Core：-
- Inductance：150 nH
- Tolerance：±20%
- Current Rating (Amps)：23.3 A
- Current - Saturation (Isat)：52A
- Shielding：Unshielded
- DC Resistance (DCR)：2.5mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 130°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.285" L x 0.268" W (7.23mm x 6.80mm)
- Height - Seated (Max)：0.118" (3.00mm)
- Features：-
Download product information
Overview
The HM72B-06R15LFTR13 is a surface-mount power inductor from the HM72B series manufactured by TT Electronics/BI Magnetics. It features an unshielded molded construction with a nominal inductance of 1.5 uH and a tolerance of ±20%. The component has a maximum DC resistance of 14 mOhms and operates within a temperature range of -40°C to +155°C. Its physical dimensions are 7.23 mm in length, 6.8 mm in width, and 3 mm in height. The device utilizes standard SMD/SMT terminations for PCB mounting and is tested at a frequency of 100 kHz.
Feature Summary
- Unshielded molded core design for high-power applications
- Wide operating temperature range up to 155°C
- Low DC resistance for efficient power handling
- Surface-mount package suitable for automated assembly
Applications
- Power supply circuits
- DC-DC converters
- General-purpose power filtering
Procurement Notes
Verify current availability status as this component may be subject to discontinuation or limited stock. Confirm RoHS compliance details and specific packaging options such as reel or cut tape directly with authorized distributors. Ensure the ordering suffix matches the required quantity format. Cross-reference the manufacturer part number with official datasheets to confirm technical specifications before procurement.
Selection Notes
Select this inductor based on its 1.5 uH inductance value and low DCR characteristics suitable for power applications. Consider the unshielded design when evaluating magnetic interference requirements. Verify that the 7.23 mm x 6.8 mm footprint fits the PCB layout constraints. Ensure the operating temperature range meets the environmental conditions of the target application.
Part Context
The HM72B series represents a line of high-performance molded surface-mount power inductors from TT Electronics/BI Magnetics. These components are designed for demanding power electronics applications requiring reliable performance across wide temperature ranges. The HM72B-06R15LFTR13 specifically offers a balance of inductance and current handling capabilities within a compact form factor.
Replacement Considerations
Publicly confirmed substitute part numbers for HM72B-06R15LFTR13 were not found in the provided source material. Consult manufacturer documentation for potential cross-references or updated series replacements.
