HM79-108R2LFTR13

$0.81

Description：FIXED IND 8.2UH 840MA 146 MOHM
Series：HM79
Mfr：TT Electronics/BI Magnetics
Package：Cut Tape (CT)

SKU:6aef035f194b Category: Fixed Inductors Brand: TT Electronics/BI Magnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FIXED IND 8.2UH 840MA 146 MOHM
Series：HM79
Mfr：TT Electronics/BI Magnetics
Package：Cut Tape (CT)
Type：Wirewound
Material - Core：-
Inductance：8.2 µH
Tolerance：±20%
Current Rating (Amps)：840 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：146mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max)：0.126" (3.20mm)
Features：-

Download product information

HM79-108R2LFTR13

Overview

The HM79-108R2LFTR13 is a shielded surface mount power inductor from the HM79 series by TT Electronics/BI Magnetics. It features an inductance of 8.2 µH with a maximum DC resistance and a rated current of 360 mA. The component operates within a temperature range of -40°C to 125°C and utilizes a standard termination type for PCB mounting.

Feature Summary

Shielded drum core construction
Surface mount package design
RoHS compliant manufacturing

Applications

General purpose power filtering
DC-DC converter input/output stages
Signal conditioning circuits

Procurement Notes

Verify manufacturer part number accuracy against official TT Electronics documentation. Confirm availability status as distribution channels may vary. Ensure compliance with RoHS standards and lead-free requirements specified in the datasheet before finalizing procurement orders.

Selection Notes

Select this component for applications requiring compact shielded inductors with moderate current handling capabilities. Consider the 8.2 µH value and 360 mA rating against circuit load requirements. Verify thermal performance within the -40°C to 125°C operating range for environmental suitability.

Part Context

This component belongs to the HM79 series of low-cost medium power surface mount inductors. The series offers various inductance values and current ratings tailored for general electronic applications, providing a balance between performance and cost-effectiveness for mass production environments.

Replacement Considerations

SDR0805-181KL by Bourns Inc. is listed as a direct substitute option. Verify electrical parameter compatibility and physical footprint alignment before implementation.
