HMC-C024

Overview

The HMC-C024 is a GaAs MMIC PHEMT distributed driver amplifier housed in a miniature, hermetic module with replaceable SMA connectors. It operates between 10 MHz and 20 GHz. The device provides 15 dB of gain with a noise figure ranging from 3 to 4 dB. It requires an operating supply voltage of 16 V and draws a supply current of 225 mA. The component utilizes connector mounting for integration into RF systems.

Feature Summary

• Utilizes GaAs MMIC PHEMT technology for distributed amplification
• Housed in a miniature, hermetic module construction
• Features replaceable SMA connectors for interface flexibility

Applications

• RF signal distribution networks
• Microwave communication systems
• Test and measurement instrumentation

Procurement Notes

Verify the specific datasheet revision and manufacturer documentation to confirm technical specifications before procurement. Ensure that the hermetic module packaging and SMA connector requirements align with system design constraints. Confirm supply chain authenticity through authorized Analog Devices channels to guarantee component integrity and performance reliability.

Selection Notes

Select this component when wideband operation up to 20 GHz is required within a hermetic package. Consider the 16 V supply requirement and 225 mA current draw during power budgeting. Evaluate the need for replaceable SMA connectors versus fixed interfaces. Assess thermal management needs for the miniature module form factor in the target application environment.

Part Context

This part belongs to the Analog Devices microwave amplifier portfolio, specifically designed for high-frequency applications. It represents a solution combining MMIC performance with robust module packaging. The product line targets engineers requiring reliable, wideband amplification in shielded environments for critical RF infrastructure.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
