HMC-C075

Overview

The HMC-C075 is a two-stage power amplifier module manufactured by Analog Devices Inc. It operates within a frequency range of 10 MHz to 6 GHz. The device provides 24 dB to 25 dB of gain and delivers +29 dBm output power at the 1 dB gain compression point. Key performance metrics include +42 dBm output IP3. The module requires a supply voltage of 15 V for operation.

Feature Summary

• Two-stage power amplifier architecture
• Wideband operational frequency coverage
• High linearity with elevated output IP3
• Integrated module design

Applications

• Wireless communication systems
• Test and measurement equipment
• Instrumentation applications

Procurement Notes

Verify the specific manufacturer datasheet for the HMC-C075 to confirm exact electrical parameters, as documentation may reference slightly varying gain figures. Ensure the required 15 V supply voltage aligns with system design constraints before procurement. Confirm package compatibility and thermal requirements for the intended application environment.

Selection Notes

Select this component when a wideband power amplification solution between 10 MHz and 6 GHz is required. The module offers high linearity suitable for demanding signal integrity applications. Consider the 15 V supply requirement during power budget planning. Evaluate the integrated module form factor against discrete solutions for size and performance optimization.

Part Context

This part belongs to the RF Amplifier IC category under Wireless & RF Integrated Circuits. It is produced by Analog Devices Inc., formerly associated with Hittite Microwave Corporation. The HMC-C075 serves as a specialized power amplifier module designed for broadband applications requiring consistent gain and linearity across its specified frequency range.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
