HP1-P10

Power Line Filter Modules Overview

The DIT HP1-P10 is a single-phase EMC/EMI line filter module designed for through-hole (TH) PCB mounting. It features a current rating of 1 A and operates at voltages up to 250 VAC/VDC with a frequency range of 50/60 Hz. The component utilizes a single-stage filtering architecture to suppress electromagnetic interference in power lines.

Power Line Filter Modules Feature Summary

• Provides single-phase EMC/EMI suppression for AC/DC power circuits
• Designed for direct through-hole PCB integration
• Supports standard 50/60 Hz line frequencies

Power Line Filter Modules Applications

• Power supply input stages requiring EMI reduction
• Electronic equipment adhering to EMC compliance standards
• Single-phase AC/DC circuit protection modules

Power Line Filter Modules Procurement Notes

Verify the specific manufacturer lead time, which may extend to approximately 40 weeks, prior to ordering. Confirm that the through-hole package style matches your PCB footprint requirements. Ensure the 1 A current rating and 250 VAC voltage specifications align with your system's electrical design constraints before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when single-stage EMI filtering is sufficient for the application. It is suitable for low-current circuits operating at standard mains frequencies. Consider the physical size and through-hole mounting requirements during PCB layout. Verify compatibility with the target voltage and current loads to ensure reliable operation without exceeding the 1 A rating.

Power Line Filter Modules Part Context

This component belongs to the DIT line filter series, focusing on basic electromagnetic interference mitigation for single-phase applications. It serves as a fundamental passive component for ensuring signal integrity and regulatory compliance in consumer and industrial electronics powered by standard AC or DC sources.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation for verified substitute part numbers. Ensure any replacement maintains the same 1 A rating, 250 VAC capability, and through-hole form factor to guarantee mechanical and electrical compatibility.
