HP1-P16

Power Line Filter Modules Overview

The HP1-P16 is a single-phase power line filter module manufactured by DIT. It provides EMC/EMI suppression for AC and DC circuits with a rated voltage of 250VAC/VDC and a current rating of 1.6A at 50/60Hz. The component utilizes through-hole (TH) pin mounting for PCB integration.

Power Line Filter Modules Feature Summary

• Single-phase electromagnetic interference filtering
• Through-hole pin termination for board mounting

Power Line Filter Modules Applications

• Electronic equipment requiring EMI suppression
• Power supply input stages
• Consumer electronics circuit protection

Power Line Filter Modules Procurement Notes

Verify the specific manufacturer lead time, which may extend to approximately 40 weeks, prior to ordering. Confirm that the 1.6A current rating and 250VAC/VDC voltage specifications align with the target application requirements. Ensure the through-hole pin configuration matches the printed circuit board layout design constraints.

Power Line Filter Modules Selection Notes

Select this component when single-phase EMI filtering is required for low-current applications up to 1.6A. The 250VAC/VDC rating suits standard low-voltage AC and DC systems. Verify compatibility with the intended operating frequency range of 50/60Hz during the design phase.

Power Line Filter Modules Part Context

DIT produces passive electronic components including capacitors and filters. The HP1-P16 belongs to their power line filter module series, designed to mitigate conducted noise in electrical circuits. This specific model addresses single-phase interference suppression needs.

Power Line Filter Modules Replacement Considerations

Consult official distributor databases for direct substitutes. Verify that any alternative part maintains identical 1.6A current, 250VAC/VDC voltage, and through-hole pin mounting specifications.
