HP1-P36

Power Line Filter Modules Overview

The DIT HP1-P36 is a single-phase EMC/EMI line filter module designed for AC power line noise suppression. It features a rated current of 3.6 A and operates at voltages up to 250 VAC at 50/60 Hz. The component utilizes a single-stage filtering architecture implemented via PC pin mounting, providing essential electromagnetic interference reduction for connected equipment.

Power Line Filter Modules Feature Summary

• Single-phase EMC/EMI line filtering capability
• PC pin mounting configuration

Power Line Filter Modules Applications

• AC power line noise suppression
• Electromagnetic interference reduction in electronic devices

Power Line Filter Modules Procurement Notes

Verify the exact part number HP1-P36 against manufacturer documentation to confirm specifications. Ensure compatibility with 250VAC systems and 3.6A current ratings. Check for any specific mounting requirements associated with the PC pin interface before integration into designs.

Power Line Filter Modules Selection Notes

Select this component when single-stage EMI filtering is required for single-phase AC applications. Confirm that the 3.6A current rating and 250VAC voltage limit meet system requirements. Verify physical space constraints for the PC pin mounting style.

Power Line Filter Modules Part Context

This component belongs to the DIT series of power line filter modules. These filters are engineered to mitigate conducted emissions on AC power lines, ensuring compliance with electromagnetic compatibility standards for various electronic apparatuses requiring noise isolation.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation or authorized distributors for verified substitute part numbers. Do not assume cross-compatibility with other manufacturers' filters without verifying electrical parameters and mounting configurations.
