HPZ1608D151-1R5TF

$0.13

Description：FERRITE BEAD 150 OHM 0603 1LN
Series：HPZ
Mfr：Shenzhen Sunlord Electronics Co., Ltd.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:1c004e5b7001 Category: Ferrite Beads and Chips Brand: Shenzhen Sunlord Electronics Co., Ltd.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HPZ1608D151-1R5TF is listed in the Chip Ferrite Bead range at ChipApex. The manufacturer field lists Shenzhen Sunlord Electronics Co., Ltd.. Its product description is FERRITE BEAD 150 OHM 0603 1LN. Review the specifications below when checking this part for your BOM.

Chip Ferrite Bead specifications for HPZ1608D151-1R5TF

Description：FERRITE BEAD 150 OHM 0603 1LN
Series：HPZ
Mfr：Shenzhen Sunlord Electronics Co., Ltd.
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：1
Impedance @ Frequency：150 Ohms @ 100 MHz
Current Rating (Max)：1.5A
DC Resistance (DCR) (Max)：70mOhm
Ratings：-
Operating Temperature：-55°C ~ 125°C
Package / Case：0603 (1608 Metric)
Mounting Type：Surface Mount
Height (Max)：0.037" (0.95mm)
Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
Features：-

Chip Ferrite Bead datasheet and documents for HPZ1608D151-1R5TF

HPZ1608D151-1R5TF

Chip Ferrite Bead Overview

The HPZ1608D151-1R5TF is a multi-layer ferrite bead manufactured by Shenzhen Sunlord Electronics Co., Ltd. It features a 0603 (1608 Metric) package and provides an impedance of 150 Ohms at 100 MHz with a tolerance of ±25%. The component has a maximum DC resistance of 70 milliohms and supports a current rating of 1.5 Amperes. It operates within a temperature range of -55°C to 125°C.

Chip Ferrite Bead Feature Summary

Multi-layer construction for compact surface-mount integration
Ferrite material for high-frequency noise suppression
Low DC resistance design for minimal signal loss

Chip Ferrite Bead Applications

Power line filtering in electronic circuits
EMI suppression in communication devices
Noise reduction in automotive electronics

Chip Ferrite Bead Procurement Notes

Verify the manufacturer part number against official Sunlord documentation to ensure authenticity. Confirm that the package dimensions match the 0603 metric standard. Check the impedance value at 100 MHz and the current rating specifications against the required circuit parameters. Ensure the operating temperature range meets the application's environmental conditions.

Chip Ferrite Bead Selection Notes

Select this component when a low-profile ferrite bead is required for power lines or data signals. The 1.5A current rating suits moderate power applications. The 150 Ohm impedance at 100 MHz targets specific frequency bands. Consider the 0603 footprint for space-constrained PCB layouts. Verify compatibility with reflow soldering profiles.

Chip Ferrite Bead Part Context

Shenzhen Sunlord Electronics Co., Ltd. is a manufacturer of chip electronic components, including magnetic and microwave devices. Their products are used in communications, consumer electronics, computers, and automotive electronics. The company focuses on providing standardized and innovative electronic solutions.
