HTSW-112-08-L-D-RA

Headers, Male Pins Overview

The HTSW-112-08-L-D-RA is a right-angle PCB header strip manufactured by Samtec Inc. It features a 0.100 inch (2.54 mm) pitch with 16 total positions arranged in a dual row configuration. The connector utilizes phosphor bronze contacts with gold plating on the mating interface and tin plating on the solder tail. Designed for through-hole mounting, it offers a natural-colored liquid crystal polymer (LCP) insulator rated UL94 V-0. The component operates within a temperature range of -55°C to 125°C and supports board-to-board or cable applications.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for compact vertical board connections
• Gold-plated mating contacts ensure reliable signal transmission
• High-temperature LCP insulation provides thermal stability

Headers, Male Pins Applications

• Board-to-board interconnects
• Cable-to-board connections
• General electronic equipment assembly

Headers, Male Pins Procurement Notes

Verify the specific part number against official Samtec documentation to confirm pin count, pitch, and termination style. Ensure compatibility with mating socket strips regarding contact retention and height specifications. Check RoHS compliance status and moisture sensitivity levels prior to procurement to meet manufacturing requirements.

Headers, Male Pins Selection Notes

Select this component when a standard 0.100 inch pitch right-angle header is required for through-hole assembly. Consider the dual-row layout for space-constrained designs needing increased I/O density. Verify that the operating temperature range and current ratings align with the system's electrical and environmental demands.

Headers, Male Pins Part Context

This part belongs to the HTSW series of classic PCB header strips from Samtec. The series is characterized by industry-leading design flexibility, offering various lead styles and plating options. These headers are widely used in prototype, development, and production environments for reliable interconnection solutions.

Headers, Male Pins Replacement Considerations

Compatible mating parts include Samtec Tiger Buy™ Socket Strips such as the SSW series. When substituting, verify that the replacement maintains the same 0.100 inch pitch, dual-row configuration, and right-angle orientation to ensure mechanical fit and electrical continuity.
