HTSW-116-09-G-D-RA

Headers, Male Pins Overview

The HTSW-116-09-G-D-RA is a right-angle header strip manufactured by Samtec Inc. It features a 2.54 mm (0.100 inch) pitch with 36 total positions arranged in a dual row configuration. The connector utilizes male pin contacts made of phosphor bronze, terminated via through-hole solder tails. Contact plating includes 10 microinches of gold on the mating interface and 3 microinches on the tail. The housing is constructed from natural liquid crystal polymer (LCP) rated UL94 V-0. It operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting for board-to-board or cable applications
• Gold-plated phosphor bronze contacts ensuring reliable signal transmission
• High-temperature resistant LCP insulation material

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic equipment assembly

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Samtec documentation to confirm contact count, plating thickness, and termination style. Ensure the selected variant matches the required PCB hole pattern and stacking height constraints. Cross-reference the RoHS compliance status with current regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a standard 0.100-inch pitch right-angle header is required for high-reliability connections. The gold plating offers superior corrosion resistance compared to tin variants. Consider the thermal stability of the LCP material for environments exceeding standard operating temperatures. Verify that the dual-row layout fits within the available PCB footprint without obstructing adjacent components.

Headers, Male Pins Part Context

This part belongs to the HTSW series of Tiger Buy™ socket strips and header strips. The series is characterized by cost-effective, high-retention contacts designed for versatile integration. The HTSW line supports various configurations including straight and right-angle orientations, accommodating diverse design needs in consumer and industrial electronics.

Headers, Male Pins Replacement Considerations

Compatible substitutes include HTSW-116-09-L-D-RA and HTSW-116-09-S-D-RA. These alternatives maintain identical mechanical dimensions and pinout but differ in contact plating specifications. Verify that the alternative plating meets the electrical and environmental requirements of the target application.
