HTSW-124-07-T-S

Headers, Male Pins Overview

The HTSW-124-07-T-S is a single-row vertical pin header manufactured by Samtec Inc. It features 24 positions with a 0.100-inch (2.54mm) mating pitch and square male pins. The connector utilizes tin-plated phosphor bronze contacts and an LCP insulator rated UL94 V-0. Designed for through-hole termination, it supports a temperature range of -55°C to 105°C. The assembly includes a natural-colored housing without a shroud, offering a push-pull fastening style suitable for board-to-board or cable applications.

Headers, Male Pins Feature Summary

• Single-row vertical design with 24 positions
• Tin-plated phosphor bronze contacts for reliable connection
• LCP insulator material with UL94 V-0 flammability rating
• Through-hole termination with push-pull fastening

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic circuit prototyping
• Industrial control panel wiring

Headers, Male Pins Procurement Notes

Verify the specific part number HTSW-124-07-T-S against official Samtec documentation to confirm contact plating and insulation material specifications. Ensure compatibility with mating connectors regarding pitch and row configuration. Check RoHS compliance status if required for your application. Confirm that the through-hole mounting style matches your PCB layout requirements.

Headers, Male Pins Selection Notes

Select this component when a single-row, 24-position header with 2.54mm spacing is required. The tin-plated contacts are suitable for standard operating conditions within the specified temperature range. Consider the push-pull fastening mechanism for secure attachment. Verify that the natural LCP housing meets environmental and flammability standards for the intended installation.

Headers, Male Pins Part Context

This part belongs to the HTSW series of high-temperature pin headers from Samtec. The series offers various configurations in terms of position count, row arrangement, and contact plating options. The HTSW-124-07-T-S represents a specific variant with tin plating and a single row, designed for robust performance in diverse electronic assemblies.

Headers, Male Pins Replacement Considerations

Consult Samtec's official cross-reference tools for verified substitutes. Ensure any replacement maintains the same 24-position count, 2.54mm pitch, and through-hole mounting style. Verify that contact material and plating meet the original electrical and environmental requirements.
