HTSW-203-07-G-S-002

Headers, Male Pins Overview

The HTSW-203-07-G-S-002 is a header connector from the Samtec HTSW series, featuring a right-angle through-hole termination style. It provides a 3-position single-row configuration with a 0.200-inch (5.08mm) pitch. The contacts are gold-plated phosphor bronze pins designed for board-to-board or cable applications. The unit utilizes a natural liquid crystal polymer insulation rated UL94 V-0 and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting for secure PCB integration
• Gold-plated phosphor bronze contacts for reliable conductivity
• Natural LCP insulation housing with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic circuit prototyping

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to ensure correct pin count, orientation, and termination type. Confirm RoHS compliance status and moisture sensitivity levels prior to procurement. Cross-reference the manufacturer part number with distributor listings to validate authenticity and current production status.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle header is required for dense PCB layouts. Ensure the mating connector matches the 0.200-inch pitch and single-row format. Consider the thermal operating range and current ratings relative to the wire gauge requirements of the target application.

Headers, Male Pins Part Context

This part belongs to the HTSW series of high-temperature terminal strips. The series offers various configurations in single and double rows with standard .100 inch and .200 inch pitches. These headers are designed for robust mechanical retention and electrical performance in demanding environments.

Headers, Male Pins Replacement Considerations

Check Samtec's official cross-reference guides for direct equivalents. Verify that any substitute maintains identical pitch, row count, and termination style to ensure mechanical compatibility.
