ICH5012S05 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 5V 50W. Review the specifications below when checking this part for your BOM.
DC DC Converters specifications for ICH5012S05
- Description：DC DC CONVERTER 5V 50W
- Series：ICH (200W)
- Mfr：XP Power
- Package：Box
- Type：Isolated Module
- Number of Outputs：1
- Voltage - Input (Min)：9V
- Voltage - Input (Max)：18V
- Voltage - Output 1：5V
- Voltage - Output 2：-
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：10A
- Power (Watts)：50 W
- Voltage - Isolation：1.5 kV
- Applications：ITE (Commercial)
- Features：Remote On/Off, OVP, SCP
- Operating Temperature：-40°C ~ 100°C
- Efficiency：81%
- Mounting Type：Through Hole
- Package / Case：9-DIP Module
- Size / Dimension：2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
- Supplier Device Package：-
- Control Features：Enable, Active High
- Approval Agency：-
- Standard Number：62368-1
- Grade：-
- Qualification：-
DC DC Converters datasheet and documents for ICH5012S05
