ICI70CGI-102

$1.69

Description：ISOLATION INDUCTOR 1 MH
Series：ICI70CGI-102
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:d03169901714 Category: Pulse Transformers Brand: EPCOS - TDK Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：ISOLATION INDUCTOR 1 MH
Series：ICI70CGI-102
Mfr：EPCOS - TDK Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Transformer Type：-
Inductance：1mH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1:01
Mounting Type：Surface Mount
Size / Dimension：0.280" L x 0.236" W (7.10mm x 6.00mm)
Height - Seated (Max)：0.189" (4.80mm)
Operating Temperature：-40°C ~ 125°C
Grade：-
Qualification：-

Download product information

ICI70CGI-102

Overview

The ICI70CGI-102 is a surface-mount isolation inductor from the EPCOS - TDK Electronics ICI70CGI series, designed for single-pair Ethernet applications. It features an inductance of 1 mH and a maximum DC resistance of 165 mOhms. The component operates within a temperature range of -40°C to +125°C. Its physical dimensions are 7.1mm x 6mm x 4.8mm. The device is RoHS compliant.

Feature Summary

Provides galvanic isolation for signal coupling
Optimized for Single Pair Ethernet (10BASE-T1L) applications
Surface mount package design

Applications

Single Pair Ethernet signal coupling
Galvanic isolation circuits
Industrial communication interfaces

Procurement Notes

Verify the specific manufacturer part number against official EPCOS - TDK Electronics documentation to ensure authenticity. Confirm that the component meets the required RoHS compliance standards for your project. Check datasheet specifications for operating temperature ranges and electrical parameters before integration.

Selection Notes

Select this component when designing circuits requiring isolation for Single Pair Ethernet connections. Ensure the 1 mH inductance value aligns with the signal frequency requirements. Verify that the surface mount footprint fits the PCB layout constraints.

Part Context

This component belongs to the ICI70CGI series of isolation inductors manufactured by EPCOS - TDK Electronics. These components are specifically engineered for high-frequency current transformer applications, providing reliable performance in industrial environments.

Replacement Considerations

Consult official TDK-EPC documentation for confirmed substitute part numbers. Do not assume cross-compatibility with other series without verifying electrical and mechanical specifications.
