ID-0242H

Power Line Filter Modules Overview

The ID-0242H is a single-phase EMC/EMI line filter module manufactured by DONG IL TECHNOLOGY LTD. It features a metal-cased miniature design with high performance, intended for products requiring compliance with FCC part 15 regulations. The unit operates at 2 A current and 250 V voltage across 50 to 60 Hz frequencies. It utilizes a single-stage filtering architecture and connects via an IEC 320-C14 inlet with quick connect terminals.

Power Line Filter Modules Feature Summary

• Metal cased miniature type construction
• High performance EMI/EMC filtering
• FCC part 15 regulation compliance suitability

Power Line Filter Modules Applications

• Electronic equipment requiring FCC part 15 compliance
• Single-phase power line noise suppression
• IEC 320-C14 compatible device integration

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation as DONG IL TECHNOLOGY LTD. when sourcing this component. Confirm the specific package style matches the IEC 320-C14 inlet requirement. Ensure the electrical ratings of 2 A and 250 V align with the target circuit design before procurement.

Power Line Filter Modules Selection Notes

Select this module for applications necessitating compact EMI/EMC filtration in single-phase systems. The metal casing provides robust shielding suitable for sensitive electronics. Verify that the quick connect terminal interface is compatible with the existing wiring harness or PCB layout constraints.

Power Line Filter Modules Part Context

This component belongs to the ID Series of power line filter modules produced by DIT. These filters are designed to mitigate electromagnetic interference in AC power lines. The series typically offers various current ratings and connection types to suit different industrial and consumer electronic standards.

Power Line Filter Modules Replacement Considerations

Cross-reference with other single-stage IEC 320-C14 filters offering 2 A capacity. Ensure any substitute maintains the same metal enclosure size and FCC compliance characteristics. Verify terminal compatibility for quick connect interfaces.
