ID-0342H

$4.23

Description：LINE FLTR 250VAC/VDC 3A PANEL
Series：ID
Mfr：DIT
Package：Tray

SKU:fed8bd3b5a14 Category: Power Line Filter Modules Brand: DIT

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ID-0342H is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists DIT. Its product description is LINE FLTR 250VAC/VDC 3A PANEL. Review the specifications below when checking this part for your BOM.

Power Line Filter Modules specifications for ID-0342H

Description：LINE FLTR 250VAC/VDC 3A PANEL
Series：ID
Mfr：DIT
Package：Tray
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：250V
Voltage - Rated AC：250V
Current：3:00 AM
Frequency - Operating：50 ~ 60Hz
Applications：General Purpose
Approval Agency：CQC, CSA, ENEC, TUV, UR, VDE
Operating Temperature：-25°C ~ 85°C
Mounting Type：Panel Mount
Termination Style：IEC 320-C14, Quick Connect
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Power Line Filter Modules datasheet and documents for ID-0342H

ID-0342H

Power Line Filter Modules Overview

The DIT ID-0342H is a single-phase EMC/EMI line filter module designed for power line noise suppression. It features a rated current of 3 A and operates at voltages up to 250 V AC or DC within the 50 to 60 Hz frequency range. The unit utilizes a single-stage filtering architecture and incorporates an IEC 320-C14 connector interface with quick-connect terminals for installation.

Power Line Filter Modules Feature Summary

Single-stage EMC/EMI noise filtration
IEC 320-C14 input connector compatibility
Quick-connect terminal mounting style

Power Line Filter Modules Applications

AC/DC power supply input filtering
Industrial equipment EMI suppression
Consumer electronics noise reduction

Power Line Filter Modules Procurement Notes

Verify that the required voltage rating does not exceed 250 V AC/DC and the continuous current load remains within the 3 A limit. Confirm mechanical compatibility with the IEC 320-C14 inlet on the target device. Ensure the application environment supports the specified operating conditions for reliable performance.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-phase solution is needed for low-frequency noise attenuation in systems requiring IEC 320-C14 connectivity. It is suitable for applications where space constraints favor integrated filter modules over discrete components, provided the current and voltage specifications align with system requirements.

Power Line Filter Modules Part Context

This part belongs to the DIT ID series of power line filter modules. These components are engineered to meet electromagnetic compatibility standards by attenuating conducted interference on mains power lines. The design integrates filtering elements directly into the connector housing to streamline assembly processes.
