ID-1022H

Power Line Filter Modules Overview

The DIT ID-1022H is a single-phase EMC/EMI line filter module designed for power line noise suppression. It features a rated current of 10 A and operates at voltages up to 250 V AC and 250 V DC within the 50–60 Hz frequency range. The unit utilizes a single-stage configuration housed in a metal case with an IEC 320-C14 inlet and quick-connect terminals.

Power Line Filter Modules Feature Summary

• Metal cased miniature construction providing high performance
• Designed to meet FCC Part 15 regulatory requirements

Power Line Filter Modules Applications

• Electronic equipment requiring FCC Part 15 compliance
• Single-phase power line noise suppression
• Industrial control systems using IEC C14 interfaces

Power Line Filter Modules Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm terminal type and voltage ratings. Ensure the component matches the required IEC 320-C14 inlet standard. Confirm active status and lead times directly with authorized distributors before finalizing procurement decisions.

Power Line Filter Modules Selection Notes

Select this component for applications requiring a compact, single-stage EMI filter with a 10 A capacity. Verify that the operating environment supports the specified 250 V AC/DC rating. Ensure mechanical fitment for the metal casing and compatibility with quick-connect wiring methods are validated during the design phase.

Power Line Filter Modules Part Context

This component belongs to the DIT ID series of power line filter modules manufactured by Dong Il Technology Ltd. The series focuses on providing compact electromagnetic interference solutions for single-phase AC power lines, utilizing metal enclosures for durability and shielding effectiveness in industrial and commercial electronic applications.

Power Line Filter Modules Replacement Considerations

Consult the official DIT cross-reference documentation for verified substitute part numbers. Do not assume functional equivalence based solely on electrical ratings; verify mounting interface and terminal configuration compatibility with the existing system design.
