ID-1022S

Power Line Filter Modules Overview

The ID-1022S is a single-phase EMC/EMI line filter module manufactured by DIT. It features a 10 A current rating and supports voltages of 250 VAC and 250 VDC. The unit operates within a frequency range of 50 to 60 Hz and utilizes a single-stage filtering design. Physical integration is facilitated via an IEC 320-C14 connector interface with solder lug termination. The component is engineered for reliable performance across an operating temperature range of -25°C to 85°C.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression through single-stage filtration
• Designed for compliance with FCC Part 15 regulatory standards
• Constructed with a metal casing for durability and shielding

Power Line Filter Modules Applications

• Industrial equipment requiring EMI mitigation
• General-purpose electronic devices needing power line filtering
• Systems mandated to meet FCC Part 15 emission limits

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from the manufacturer or authorized distributor to confirm exact electrical specifications and mechanical dimensions. Ensure the solder lug termination method aligns with the target PCB layout. Confirm that the IEC 320-C14 mating connector is compatible with the intended power inlet assembly before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a single-phase, 10 A rated filter is required for AC mains applications. The solder lug termination dictates the mounting strategy on the printed circuit board. Consider the -25°C to 85°C operational range to ensure suitability for the environmental conditions of the end product.

Power Line Filter Modules Part Context

This part belongs to the ID series of power line filter modules from DIT. These components are designed to attenuate conducted noise on power lines. The series typically includes variants with different voltage ratings and connector types, such as the ID-1022H, which may offer panel mount configurations instead of solder lugs.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing IEC 320-C14 connectors and PCB footprint requirements when evaluating alternative single-stage EMI filters.
