IFLN1812CZER601N

$0.60

Description：CMC 11UH 360MA 2LN 4 KOHM SMD
Series：IFLN-1812CZ
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:53ce18ceadc0 Category: Common Mode Chokes Brand: Vishay Dale

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IFLN1812CZER601N is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Vishay Dale. Its product description is CMC 11UH 360MA 2LN 4 KOHM SMD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for IFLN1812CZER601N

Description：CMC 11UH 360MA 2LN 4 KOHM SMD
Series：IFLN-1812CZ
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：360mA
DC Resistance (DCR) (Max)：600mOhm
Voltage Rating - DC：50V
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 150°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.177" L x 0.126" W (4.50mm x 3.20mm)
Height (Max)：0.118" (3.00mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：11 µH @ 100 kHz
Impedance @ Frequency：4 kOhms @ 100 MHz
Qualification：-
Grade：-

Common Mode Chokes datasheet and documents for IFLN1812CZER601N

IFLN1812CZER601N

Common Mode Chokes Overview

The Vishay Dale IFLN1812CZER601NA is a single-channel common mode choke filter designed for surface mount technology. It features an unshielded construction within a compact SMD-4 package measuring 4.5 mm in length, 3.2 mm in width, and 2.8 mm in height. The component provides an inductance of 11 uH with a tolerance range of -30% to +50%. It exhibits a high impedance of 4 kOhms at a test frequency of 100 MHz and maintains a maximum DC resistance of 600 mOhms. The device operates reliably within a temperature range of -55°C to +150°C.

Common Mode Chokes Feature Summary

Provides high impedance filtering for common mode noise suppression in signal lines.
Features unshielded construction suitable for applications where magnetic shielding is not required.
Supports operation across an extended industrial temperature range from -55°C to +150°C.

Common Mode Chokes Applications

Signal line filtering
Common mode noise suppression

Common Mode Chokes Procurement Notes

Verify the exact part number suffix against official Vishay documentation, as variations may exist. Confirm availability status directly with authorized distributors, as supply constraints have been noted. Ensure the selected component matches the specific impedance and inductance requirements for the target circuit design before finalizing procurement orders.

Common Mode Chokes Selection Notes

Select this component when high impedance at 100 MHz is required for common mode noise reduction. The wide operating temperature range makes it suitable for harsh environments. Consider the unshielded nature of the device regarding potential electromagnetic interference interactions with nearby components on the PCB layout.

Common Mode Chokes Part Context

This component belongs to the IFLN series of common mode chokes manufactured by Vishay / Dale. It utilizes a multilayer ceramic or similar technology typical for high-frequency signal line protection. The 1812 footprint allows for automated surface mount assembly, integrating easily into modern electronic manufacturing processes.
