IG-0242P

Power Line Filter Modules Overview

The IG-0242P is a single-phase EMC/EMI line filter manufactured by DIT (Dong Il Technology). It is rated for 2 A current and 250 VAC/VDC voltage at 50 to 60 Hz frequencies. The component features a single-stage design intended for power line filtering applications. It utilizes an IEC 320-C14 connector interface and employs PC pin termination for mounting.

Power Line Filter Modules Feature Summary

• Single-phase EMI/EMC line filtering capability
• IEC 320-C14 connector interface
• PC pin termination style

Power Line Filter Modules Applications

• Power line filtering in electronic equipment
• EMC compliance for AC powered devices

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation DIT corresponds to Dong Il Technology when sourcing components. Confirm that the IEC 320-C14 connector orientation and PC pin spacing match the target PCB layout requirements. Ensure the 2 A rating and 250 VAC specification align with the system's electrical load and voltage constraints before integration.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-stage EMI suppression with standard IEC C14 connectivity. The PC pin configuration suits through-hole PCB assembly processes. Evaluate the 2 A current capacity against peak operational loads to ensure adequate performance margins within the specified 50 to 60 Hz frequency range.

Power Line Filter Modules Part Context

This part belongs to the category of power line filters designed for electromagnetic interference reduction. It serves as a passive component to suppress noise on AC power lines, ensuring regulatory compliance for electronic devices operating at standard mains frequencies.
