IG-0242S

Power Line Filter Modules Overview

The DIT IG-0242S is a single-phase EMC/EMI line filter module designed for panel mounting. It operates at a rated current of 2 A and supports voltage ratings of 250 VAC/VDC within a 50–60 Hz frequency range. The component features a single-stage filtering configuration to suppress electromagnetic interference in power lines.

Power Line Filter Modules Feature Summary

• Single-phase EMI/EMC line filtering capability
• Panel-mount installation design
• Supports 250 VAC/VDC operation

Power Line Filter Modules Applications

• Power supply input filtering
• Electronic equipment noise suppression
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the exact manufacturer designation, as 'DIT' may refer to the product family or a distributor code rather than the original component producer. Confirm the specific datasheet source to ensure compliance with safety standards and electrical ratings before integration into final designs.

Power Line Filter Modules Selection Notes

Select this component when single-stage attenuation is sufficient for the application's noise profile. Ensure the operating environment remains within the specified 250 VAC/VDC and 2 A limits. Verify physical dimensions for panel cutout compatibility during mechanical design.

Power Line Filter Modules Part Context

This part belongs to the category of passive electromagnetic interference filters used in AC/DC power interfaces. It serves to mitigate conducted emissions generated by downstream loads or incoming line disturbances, ensuring regulatory compliance for electronic devices.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-referencing requires matching electrical specifications (2A, 250V) and form factor with other manufacturers' single-phase line filter catalogs.
