IG-0342S

Power Line Filter Modules Overview

The IG-0342S is a single-phase EMC/EMI line filter module manufactured by DIT. It is rated for a current of 3 A and operates at voltages up to 250 VAC. The unit supports frequencies in the 50 to 60 Hz range and utilizes a single-stage filtering design. The component features an IEC 320-C14 connector interface and employs solder lug termination methods for circuit board integration.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression through single-stage filtering architecture
• Designed for single-phase power line applications with standard IEC connectivity
• Utilizes solder lug termination for secure PCB mounting

Power Line Filter Modules Applications

• Single-phase electronic equipment requiring EMI suppression
• Power supply input stages for consumer electronics
• Industrial control units operating on standard AC mains

Power Line Filter Modules Procurement Notes

Verify that the required current rating of 3 A meets the specific load requirements of the target application. Confirm compatibility with the 250 VAC maximum voltage specification. Ensure the IEC 320-C14 connector type matches the mating inlet on the host device. Check that the solder lug termination method aligns with the printed circuit board layout and assembly process capabilities.

Power Line Filter Modules Selection Notes

Select this component when a single-stage EMI filter is sufficient for noise reduction needs. Consider the physical dimensions and mounting constraints associated with solder lug terminations. Evaluate if the 3 A current capacity provides adequate margin for peak loads. Verify that the single-phase configuration matches the system power distribution architecture.

Power Line Filter Modules Part Context

This component belongs to the category of power line filter modules designed for electromagnetic compatibility. It serves as a passive filtering element placed between the power source and sensitive electronic loads. The design focuses on attenuating high-frequency noise while allowing the passage of the fundamental power frequency.

Power Line Filter Modules FAQ

What is the maximum operating voltage for the IG-0342S?

The maximum operating voltage is 250 VAC.

Does the IG-0342S support three-phase connections?

No, it is a single-phase filter module.
