IG-0642S

Power Line Filter Modules Overview

The DIT IG-0642S is a single-phase EMC/EMI line filter module designed for AC power line applications. It supports a rated current of 6 A and operates at voltages up to 250 V AC within the 50 to 60 Hz frequency range. The unit features a single-stage filtering architecture to suppress electromagnetic interference. Mechanical integration utilizes IEC 320-C14 connectors with solder lug termination methods, ensuring secure connection in electronic assemblies.

Power Line Filter Modules Feature Summary

• Provides single-stage electromagnetic interference suppression for AC power lines
• Utilizes IEC 320-C14 interface with solder lug termination for board mounting
• Engineered for single-phase power distribution systems

Power Line Filter Modules Applications

• AC power input stages in electronic equipment
• Electromagnetic compatibility filtering for consumer electronics
• Industrial control system power supplies

Power Line Filter Modules Procurement Notes

Verify that the specific batch matches the IEC 320-C14 connector specification and 6 A current rating. Confirm solder lug dimensions against the target PCB layout. Ensure the component meets regional safety certifications required for the final assembly destination. Request test reports for insertion loss characteristics if strict EMI compliance is mandated by the end product design.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-stage solution is required for 6 A single-phase AC lines. The IEC 320-C14 interface simplifies mechanical integration compared to wire-wound alternatives. Consider the solder lug termination method for automated assembly processes. Evaluate the physical footprint against available space on the main circuit board or power entry module area.

Power Line Filter Modules Part Context

This part belongs to the DIT power line filter module series, which focuses on integrated EMC solutions for AC mains inputs. The IG-0642S variant specifically addresses standard household and light industrial voltage ranges. It serves as a primary defense stage against conducted noise before it enters sensitive downstream circuitry.

Power Line Filter Modules Replacement Considerations

Cross-reference with other single-stage IEC 320-C14 filters rated at 6 A. Verify identical pinout configurations and terminal types to ensure mechanical compatibility without PCB redesign.
