IH-0242H

Power Line Filter Modules Overview

The IH-0242H is a power line filter module designed for panel mounting applications. It utilizes IEC 320-C14 connectors and quick connect terminals for integration. The unit operates within a temperature range of -25°C to 85°C. It holds multiple safety certifications including CQC, CSA, ENEC, TUV, UR, and VDE compliance. The component functions as an electromagnetic interference suppression device for AC power inputs.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference filtering for AC power lines
• Features IEC 320-C14 connector interface with quick connect termination
• Supports panel mounting installation method
• Complies with international safety standards including TUV and VDE

Power Line Filter Modules Applications

• AC power input filtering for electronic equipment panels
• Industrial control system power supply interfaces
• Commercial appliance power entry modules

Power Line Filter Modules Procurement Notes

Verify the specific current rating and voltage classification required for the target application against the manufacturer datasheet. Confirm that the IEC 320-C14 mating connector compatibility matches existing harness designs. Ensure environmental conditions remain within the specified -25°C to 85°C operating range for reliable performance.

Power Line Filter Modules Selection Notes

Select this component when panel-mount power line filtering is required with standard IEC 320-C14 interfaces. Consider the thermal operating limits and certification requirements for the target market. Evaluate space constraints for panel mounting versus PCB-mounted alternatives if form factor differs from available options.

Power Line Filter Modules Part Context

This part belongs to the DIT power line filter series. It serves as a passive component for noise suppression in AC power circuits. The design focuses on robust mechanical integration via panel mounting and standardized electrical connections for easy assembly into larger systems.

Power Line Filter Modules Replacement Considerations

Check for compatible filters with identical IEC 320-C14 interfaces and similar current ratings. Verify that substitute components meet the same safety certifications (TUV, VDE) and operate within the required temperature range.
