IH-0642H

Power Line Filter Modules Overview

The IH-0642H is a single-phase EMC/EMI line filter module manufactured by DIT. It is rated for 6 A at 250VAC with a frequency range of 50 to 60Hz. The unit features a single-stage design and utilizes an IEC 320-C14 input connector with quick connect terminals. It is housed in a metal case and supports panel mounting. The operating temperature range spans from -25°C to 85°C.

Power Line Filter Modules Feature Summary

• Metal cased miniature construction providing high performance
• Designed to conform to FCC part 15 regulations
• Single-stage EMC/EMI filtering capability

Power Line Filter Modules Applications

• Electronic equipment requiring FCC part 15 compliance
• Power supply input filtering for AC mains
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the specific certification marks required for your target market, as this model lists CQC, CSA, ENEC, TUV, UR, and VDE approvals. Confirm that the quick connect terminal style matches your wiring harness or PCB layout requirements. Ensure the panel mounting dimensions align with your enclosure design constraints before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a compact, metal-cased EMI filter is needed for single-phase AC applications up to 6A. The IEC 320-C14 interface simplifies integration into standard power entry modules. Consider the wide operating temperature range if the device will be used in environments subject to significant thermal variation.

Power Line Filter Modules Part Context

This component belongs to DIT's line of power line filter modules. These units are engineered to suppress electromagnetic interference generated by electronic devices, ensuring they do not disrupt other equipment and remain immune to external noise sources within the specified current and voltage ratings.

Power Line Filter Modules Replacement Considerations

Cross-reference with other DIT models offering similar 6A ratings and IEC 320-C14 interfaces. Verify that any substitute maintains the same metal casing, panel mounting style, and approved regulatory certifications for your specific application region.
