IH-0642S

Power Line Filter Modules Overview

The DIT IH-0642S is a single-phase EMC/EMI line filter module designed for AC power lines. It operates at 250V AC with a rated current of 6A and supports frequencies of 50 to 60Hz. The unit implements a single-stage filtering architecture compliant with IEC standards. This component is engineered to suppress electromagnetic interference in electrical circuits, ensuring signal integrity and regulatory compliance for connected devices.

Power Line Filter Modules Feature Summary

• Single-stage EMI suppression architecture
• IEC standard compliance for AC power lines
• Compact module design for integration

Power Line Filter Modules Applications

• AC power line noise reduction
• EMC compliance for electronic equipment
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the specific IEC standard designation and exact attenuation characteristics against the manufacturer's datasheet before integration. Confirm that the 6A rating and 250V AC specifications align with the target circuit requirements. Ensure mounting constraints accommodate the module dimensions. Cross-reference terminal types and wiring diagrams to guarantee correct installation and operational safety.

Power Line Filter Modules Selection Notes

Select this filter when single-stage attenuation is sufficient for the application's noise profile. The 6A current capacity suits moderate-power loads. Verify compatibility with 50/60Hz mains frequencies. Consider physical size constraints as it is a compact module. Ensure the voltage rating meets or exceeds the system's maximum operating voltage for reliable performance.

Power Line Filter Modules Part Context

DIT manufactures passive electronic components, including filters and capacitors. The IH-0642S belongs to their line filter series, focusing on electromagnetic compatibility solutions. These components are typically used in industrial and commercial electronics to mitigate conducted emissions and improve system reliability by filtering high-frequency noise from power supplies.

Power Line Filter Modules FAQ

What is the maximum current rating?

The maximum continuous current rating is 6A.

Is this filter suitable for DC applications?

No, it is specified for AC power lines at 250V AC, 50-60Hz.
