IH-15A2H

Power Line Filter Modules Overview

The IH-15A2H is a single-phase EMC/EMI line filter module manufactured by DIT (Dong Il Technology). It is rated for a continuous current of 15 A and operates at voltages up to 250 V AC within the 50–60 Hz frequency range. The unit utilizes a single-stage filtering architecture and features an IEC 320-C14 input connector interface with quick-connect terminals for circuit integration.

Power Line Filter Modules Feature Summary

• Single-stage EMI/EMC noise suppression
• IEC 320-C14 connector compatibility
• Quick-connect terminal configuration

Power Line Filter Modules Applications

• Single-phase power line filtering
• EMC compliance in electronic equipment
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation DIT corresponds to Dong Il Technology Ltd. Confirm the specific voltage rating of 250V and current capacity of 15A match system requirements. Ensure the IEC 320-C14 interface and quick-connect termination style are compatible with the target PCB or wiring harness design before procurement.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-phase noise attenuation in compact form factors. The 15A rating suits moderate power loads, while the 250V specification aligns with standard low-voltage AC distribution networks. The quick-connect feature facilitates rapid assembly in manufacturing environments requiring standardized power entry modules.

Power Line Filter Modules Part Context

This part belongs to the category of power line filter modules designed for electromagnetic interference reduction. It serves as a passive component to ensure regulatory compliance by attenuating conducted emissions on AC power lines, distinct from active filtering solutions or multi-phase industrial filters.

Power Line Filter Modules Replacement Considerations

Cross-reference with other single-phase 15A EMI filters featuring IEC 320-C14 inputs. Verify that substitute parts maintain identical current ratings, voltage limits, and terminal connection types to ensure mechanical and electrical interchangeability without redesigning the enclosure or wiring.
