IHDM1107BBEV3R0M20

$9.75

Description：FG, IHDM-1107BB-20 3.0 20%
Series：IHDM-1107BB-20
Mfr：Vishay Dale
Package：Bulk

SKU:2ce57a203362 Category: Fixed Inductors Brand: Vishay Dale

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IHDM1107BBEV3R0M20 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Vishay Dale. Its product description is FG, IHDM-1107BB-20 3.0 20%. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for IHDM1107BBEV3R0M20

Description：FG, IHDM-1107BB-20 3.0 20%
Series：IHDM-1107BB-20
Mfr：Vishay Dale
Package：Bulk
Type：Drum Core, Wirewound
Material - Core：Iron Powder
Inductance：3 µH
Tolerance：±20%
Current Rating (Amps)：50 A
Current - Saturation (Isat)：192A
Shielding：Unshielded
DC Resistance (DCR)：0.97mOhm Max
Q @ Freq：-
Frequency - Self Resonant：53MHz
Ratings：-
Operating Temperature：-55°C ~ 180°C
Inductance Frequency - Test：100 kHz
Mounting Type：Through Hole
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：1.055" L x 0.705" W (26.80mm x 17.90mm)
Height - Seated (Max)：0.882" (22.40mm)
Features：-

Fixed Inductors datasheet and documents for IHDM1107BBEV3R0M20

IHDM1107BBEV3R0M20

Fixed Inductors Overview

The IHDM1107BBEV3R0M20 is a leaded power inductor from Vishay Dale, designed for high-current applications. It features an unshielded drum core construction with iron powder material. The component offers an inductance of 3 uH with a tolerance of 20%. It supports a maximum DC current of 50 A and a saturation current of 192 A. The maximum DC resistance is 970 uOhms. Operating temperatures range from -40 C to +180 C. The self-resonant frequency is 53 MHz. Dimensions are 26.8 mm length, 17.9 mm width, and 22.4 mm height. It utilizes solder tab termination for PCB mounting.

Fixed Inductors Feature Summary

High saturation current capability up to 192 A
Wide operating temperature range up to 180 C
Unshielded drum core design for thermal efficiency
Solder tab termination for robust PCB integration

Fixed Inductors Applications

DC-DC Converter
Power Factor Correction
DC Battery Filter

Fixed Inductors Procurement Notes

Verify the specific suffix M20 corresponds to the bulk packaging configuration as indicated in official distributor listings. Confirm that the solder tab termination matches the target PCB footprint requirements. Ensure the 180 C maximum operating temperature rating aligns with the thermal management strategy of the final assembly. Cross-reference the 970 uOhms DCR specification against circuit loss constraints.

Fixed Inductors Selection Notes

Select this component when high current handling and elevated temperature operation are required. The 192 A saturation current makes it suitable for heavy-duty power stages. Compare the 970 uOhms DCR against alternative packages to balance conduction losses. Verify that the unshielded nature does not interfere with nearby sensitive components due to magnetic field exposure.

Fixed Inductors Part Context

This part belongs to the IHDM-1107BB series of leaded power inductors. It shares the same physical envelope and core technology with other variants in the family, differing primarily in inductance value and current ratings. The series is characterized by its iron powder core and high thermal stability, targeting industrial and automotive power supply designs.
