IHLP2525CZER1R5MA1

Description：IHLP-2525CZ-A1 1.5 20% ER E3
Series：IHLP-2525CZ-A1
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:b3d43cd606fe Category: Fixed Inductors Brand: Vishay Dale

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IHLP2525CZER1R5MA1 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Vishay Dale. Its product description is IHLP-2525CZ-A1 1.5 20% ER E3. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for IHLP2525CZER1R5MA1

Description：IHLP-2525CZ-A1 1.5 20% ER E3
Series：IHLP-2525CZ-A1
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：Metal Composite
Inductance：1.5 µH
Tolerance：±20%
Current Rating (Amps)：9:00 AM
Current - Saturation (Isat)：18A
Shielding：Shielded
DC Resistance (DCR)：15mOhm Max
Q @ Freq：-
Frequency - Self Resonant：40MHz
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.270" L x 0.255" W (6.86mm x 6.47mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for IHLP2525CZER1R5MA1

IHLP2525CZER1R5MA1

Fixed Inductors Overview

The IHLP2525CZER1R5MA1 is a shielded surface-mount power inductor from Vishay Dale, designed for high-current applications. It features an inductance of 1.5 µH with a tolerance of ±20%. The component has a maximum DC resistance of 15 mΩ and supports a saturation current of 9 A. It operates within a temperature range of -55°C to +125°C and achieves a self-resonant frequency of 40 MHz. The package dimensions are 6.86 mm x 6.47 mm x 3.0 mm.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference
AEC-Q200 qualified for automotive reliability
Composite core material for stable performance

Fixed Inductors Applications

Automotive DC/DC converters
High current power supplies
On-board charging systems

Fixed Inductors Procurement Notes

Verify the specific suffix 'ER' confirms the AEC-Q200 qualification status required for automotive integration. Confirm that the 15 mΩ DCR and 9 A saturation current meet the target circuit's thermal and efficiency constraints. Ensure the 2525 footprint matches the PCB layout guidelines provided in the official datasheet.

Fixed Inductors Selection Notes

Select this component when automotive-grade reliability is mandatory alongside low profile requirements. The 1.5 µH value suits intermediate switching frequencies where compact size is critical. Compare against non-automotive variants if cost sensitivity outweighs the need for AEC-Q200 certification.

Fixed Inductors Part Context

This part belongs to the IHLP-2525CZ series, which focuses on low-profile, high-current solutions. The CZ designation indicates a specific core material optimized for high saturation. The Z suffix typically denotes the standard height variant within this footprint family.
