IMC101TF064XUMA1

Overview

The IMC101TF064XUMA1 is a three-phase brushless DC motor controller from the iMOTION series, manufactured by Infineon Technologies. It operates within a supply voltage range of 3 V to 5.5 V and delivers an output current of 50 mA. The device functions at a working frequency of 16 kHz with a power consumption of 10 mA. Designed for surface mount installation, it utilizes a 64-pin LQFP package (PG-LQFP-64-26). The component supports analog and PWM interfaces and is rated for operation between -40°C and +105°C.

Feature Summary

• Integrates MCE 2.0 control engine with scripting capabilities for flexible motor management
• Supports both analog and PWM input interfaces for versatile control integration
• Designed specifically for three-phase brushless DC motor applications

Applications

• Home appliance motor drives
• Industrial automation systems
• Consumer electronics motor control

Procurement Notes

Verify the specific suffix XUMA1 against official Infineon documentation to confirm reel packaging specifications. Confirm that the part status remains appropriate for your design lifecycle, as availability may vary. Ensure compatibility with your system's voltage and thermal requirements before finalizing procurement decisions.

Selection Notes

Select this component when a dedicated three-phase BLDC controller with integrated scripting is required. It is suitable for designs needing 50 mA output drive capability within a compact 64-pin LQFP footprint. Consider its analog/PWM interface support if external microcontroller complexity needs reduction.

Part Context

This part belongs to the iMOTION IMC100 series, which integrates motor control engines with flash memory. It targets single-motor applications without integrated power stages, distinguishing it from PFC-integrated variants in the broader iMOTION portfolio.

Replacement Considerations

IMC101T-F048 (IMC101TF048XUMA1) offers similar functionality in a smaller 48-pin package.
