IMC1812BN3R3K

$0.53

Description：FIXED IND 3.3UH 355MA 800MOHM SM
Series：IMC-1812
Mfr：Vishay Dale
Package：Bulk

SKU:5761b6e2a533 Category: Fixed Inductors Brand: Vishay Dale

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IMC1812BN3R3K is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Vishay Dale. Its product description is FIXED IND 3.3UH 355MA 800MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for IMC1812BN3R3K

Description：FIXED IND 3.3UH 355MA 800MOHM SM
Series：IMC-1812
Mfr：Vishay Dale
Package：Bulk
Type：Drum Core, Wirewound
Material - Core：Iron Powder
Inductance：3.3 µH
Tolerance：±10%
Current Rating (Amps)：355 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：800mOhm Max
Q @ Freq：50 @ 7.96MHz
Frequency - Self Resonant：45MHz
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：7.96 MHz
Mounting Type：Surface Mount
Package / Case：1812 (4532 Metric)
Supplier Device Package：1812
Size / Dimension：0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)：0.134" (3.40mm)

Fixed Inductors datasheet and documents for IMC1812BN3R3K

IMC1812BN3R3K

Fixed Inductors Overview

The IMC1812BN3R3K is a surface-mount RF inductor from the Vishay Dale IMC series, designed for radio frequency applications. It features a molded construction with standard terminations suitable for PCB mounting. The component has an inductance of 3.3 uH and a maximum DC resistance of 550 mOhms. It supports a maximum DC current of 357 mA and operates within a temperature range of -55 C to +125 C.

Fixed Inductors Feature Summary

Molded construction for robust performance
Standard SMD/SMT terminations for PCB integration
Optimized for RF circuit environments

Fixed Inductors Applications

RF circuits
PCB Mount applications

Fixed Inductors Procurement Notes

Verify the specific electrical parameters against the official Vishay / Dale datasheet before procurement. Confirm that the 3.3 uH inductance and 357 mA current rating align with the design requirements. Ensure the 1812 package dimensions match the target PCB layout. Check RoHS compliance status as indicated in the product documentation.

Fixed Inductors Selection Notes

Select this component when a 3.3 uH value is required in a 1812 footprint. Consider the 550 mOhms DCR and 357 mA current limit for power handling. Compare against other molded or wirewound options if shielding or different tolerance levels are needed. Verify thermal limits for the intended operating environment.

Fixed Inductors Part Context

This part belongs to the IMC series of RF inductors manufactured by Vishay / Dale. It shares the 1812 (4532 metric) package form factor with other variants in the line. The series includes various inductance values and tolerance options, all utilizing similar mounting styles and construction types for consistent assembly processes.
