Product Detailed Parameters
- Description：IMOTION
- Series：iMOTION™
- Mfr：Infineon Technologies
- Package：Tape & Reel (TR)
- Motor Type - Stepper：Multiphase
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Driver - Fully Integrated, Control and Power Stage
- Output Configuration：Half Bridge (3)
- Interface：-
- Technology：Power MOSFET
- Step Resolution：-
- Applications：General Purpose
- Current - Output：-
- Voltage - Supply：-
- Voltage - Load：-
- Operating Temperature：-
- Mounting Type：Surface Mount
- Package / Case：38-PowerVQFN
- Supplier Device Package：PG-IQFN-38-1
- Grade：-
- Qualification：-
Download product information
Overview
The Infineon Technologies IMM100A056MXUMA1 is a multiphase motor driver integrated circuit belonging to the iMOTION family. It integrates power MOSFETs and control logic for precise motor management. The device operates within a supply voltage range of 13.5 V to 16.5 V and supports an output current of 4 A. It utilizes a 38-PowerVQFN package with surface mount installation. The component functions as a half-bridge driver with three outputs and accepts PWM interface signals. It is designed for demanding applications requiring advanced motor control features.
Feature Summary
- Integrates power MOSFETs and control logic for precise motor management
- Supports multiphase motor driving capabilities
- Accepts PWM interface signals for control
Applications
- General purpose motor control systems
- Demanding industrial motion applications
- Automotive ignition or motion controllers
Procurement Notes
Verify the specific suffix MXUMA1 against official Infineon documentation to confirm package type and tape/reel specifications. Confirm RoHS compliance status and moisture sensitivity level (MSL) requirements prior to PCB assembly. Check for end-of-life or not recommended for new design (NRND) status in current manufacturer catalogs before finalizing procurement plans.
Selection Notes
Select this component when a multiphase driver with integrated power stages is required. Ensure the application voltage stays within the 13.5 V to 16.5 V range. Verify that the 38-PowerVQFN footprint fits the board layout. Consider thermal performance requirements given the 4 A output capability and PowerVQFN packaging constraints.
Part Context
This part belongs to the Infineon iMOTION series, which focuses on intelligent motor control solutions. The IMM100 series typically targets applications needing compact, high-performance motor drivers. It serves as a specialized PMIC solution for managing brushless DC motors or similar loads in constrained spaces.
Replacement Considerations
IMM101T056MXUMA1 and IMM101T015MXUMA1 are listed as potential substitutes by distributors. Verify pinout compatibility and electrical parameter alignment with official datasheets before substitution.
