IMSA-13065B-2-28Y902

Headers, Male Pins Overview

The IMSA-13065B-2-28Y902 is a surface mount right-angle header connector manufactured by IRISO USA Inc. It features 28 positions with a 2.00mm (0.079") mating pitch and 2.50mm (0.098") row spacing. The connector utilizes square male pins made of copper alloy, finished with 1.00µm (39.4µin) tin plating. Constructed with black polyphenylene sulfide (PPS) insulation rated UL94 V-0, it has an insulation height of 9.30mm (0.366"). This component includes a four-wall shielded cover and employs a locking pin slide fastening mechanism.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for board-to-board or cable applications
• Four-wall shielded cover for enhanced protection
• Locking pin slide fastening mechanism for secure connection

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable connections
• Automotive electronics systems

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm keying configuration and contact count. Ensure compatibility with mating connectors regarding pitch and shielding requirements. Confirm that the surface mount footprint matches the target PCB layout. Check for RoHS compliance status if required by project specifications. Validate that the locking mechanism aligns with assembly processes.

Headers, Male Pins Selection Notes

Select this connector when a right-angle surface mount header with shielding is required. The 2.00mm pitch suits dense circuit layouts. The four-wall shield provides EMI protection. Verify that the 28-position count meets signal routing needs. Consider the PPS material for thermal stability during soldering.

Headers, Male Pins Part Context

This part belongs to the IRISO 13065B series of rectangular headers. The series offers various position counts and keying options. The 'B' designation typically indicates specific housing characteristics within the product line. These connectors are designed for reliable performance in industrial and automotive environments.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.00mm pitch, 28 positions, right-angle SMT form factor, and four-wall shield. Verify that any replacement maintains the same locking pin slide mechanism and UL94 V-0 insulation rating. Cross-reference the mating interface dimensions to ensure mechanical compatibility.
