IMSA-13103B-02Y900

Headers, Male Pins Overview

The IMSA-13103B-02Y900 is a surface mount, right-angle header connector manufactured by IRISO USA Inc. It features a 2-position configuration with a 2.00mm (0.079 inch) pitch. The component utilizes square male pins with tin plating and a PPS insulator. Rated for 50VAC and 3A, it operates within a -40°C to 125°C temperature range. The housing is black, and the connector includes a four-wall shielded shroud with a locking base for secure attachment.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Positive locking mechanism ensures secure mating stability
• Four-wall shielded shroud provides environmental protection

Headers, Male Pins Applications

• Embedded systems interconnection
• Industrial automation control boards
• Wire-to-board connections in consumer electronics

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm pin count and orientation. Ensure compatibility with existing PCB footprints and mating connectors. Confirm RoHS compliance status and moisture sensitivity level requirements for your assembly process before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle SMT header is required for two-wire connections. The 2.00mm pitch suits general-purpose signal transmission. Consider the locking feature for vibration-prone environments. Verify that the 3A current rating meets the circuit load requirements and that the operating temperature range aligns with the application environment.

Headers, Male Pins Part Context

This part belongs to the IMSA-13103B series of wire-to-board connectors from IRISO USA Inc. The series offers various position counts and configurations. The 'B' designation typically indicates a specific housing or contact type variant within the product line, designed for reliable board-to-cable interconnections in industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Direct substitutes are not explicitly confirmed in public documentation. Evaluate competitors offering 2.00mm pitch, SMT right-angle headers with similar locking mechanisms. Verify dimensional compatibility and electrical ratings before substitution.
