IMSA-13103B-04Y900

Headers, Male Pins Overview

The IMSA-13103B-04Y900 is a surface mount right-angle header manufactured by IRISO USA Inc. It features a 2.00mm pitch and four positions with male pins. The connector utilizes PPS insulation, tin-plated copper alloy contacts, and a positive locking latch system. Rated for 50VAC and 3A, it operates within a -40°C to 125°C range.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Positive locking mechanism ensures secure mating stability
• Tin-plated contacts provide reliable electrical conductivity
• PPS insulation material supports high thermal resistance

Headers, Male Pins Applications

• Board-to-cable interconnections
• Board-to-wire connections
• General PCB header applications

Headers, Male Pins Procurement Notes

Verify the specific suffix Y900 against official IRISO documentation to confirm keying and orientation details. Ensure compatibility with mating connectors in the 13103B series. Confirm RoHS3 compliance status through current manufacturer datasheets before finalizing procurement specifications.

Headers, Male Pins Selection Notes

Select this component for applications requiring a low-profile, right-angle connection with a 2.00mm pitch. The positive locking feature is suitable for environments requiring vibration resistance. Verify that the 3A current rating and 50VAC voltage limit meet the circuit requirements.

Headers, Male Pins Part Context

This part belongs to the IRISO 13103B series of wire-to-board connectors. The series offers various pin counts and configurations, all sharing a consistent 2.00mm pitch and locking mechanism. This specific model represents the four-position variant designed for surface mount technology.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other models within the IRISO 13103B series with matching pitch and locking features. Cross-reference pin count and orientation carefully when evaluating alternative sources or equivalent components from other manufacturers.
